Meike 75mm T2.1 S35 Cine lens PL Mount

Meike 75mm T2.1 S35 Cine lens PL Mount

Meike is moving fast – after the launch of the Meike 75mm T/2.1 FF-Prime, they just introduced a new lineup of S35 lenses with this 75mm T/2.1 S35-Prime.
The complete lens set will consist of an 18mm, 25mm, 35mm, 50mm, 75mm, and 105mm all at T/2.1.
This 35mm lens features an image circle of 33.6mm and covers Super 35 sensors with a maximum resolution of 6K – meaning that it is compatible with a wide range of cameras, including the Canon C200, Blackmagic Design Pocket Cinema Camera 4k/6K, the RED Komodo, and so on.

The housing of the 75mm T/2.1 S35-Prime is made out of aluminum. It will soon be available in either EF mount (940g/2.07lbs) or PL mount (910g/2lbs), yet the lens mount is not user interchangeable.

The lens has industry-standard 0.8mm pitch gears on the focus and aperture ring, while the focus ring has a focus throw of 270 degrees.

Lens Design

The design of this 75mm T/2.1 S35 lens consists of twelve elements in ten groups. The aperture mechanism consists of eleven aperture blades, and the minimum focus distance is 48cm.
The outside diameter of the lens is 80mm, which is cinema standard. If you have a clamp-on matte box – such as the Tilta Mini Mattebox – it should work just fine. Also, you can screw 77mm filters directly in front of the lens.

Specifications:

• Lens Mount: PL
• Min Focal Dist: 48cm
• Filter Thread: ø77
• Structure: 12 Elements in 10 Groups
• Focal Length: 35mm
• Aperture Range: T2.1-T22
• Iris Blades: 11
• Gear Mod: M0.8
• Focus Rotation: 270 Degree
• Dimensions (Ø x L):
• PL: φ80 ×98.5 mm
• EF: φ80 × 106.5mm
FOV:
• Diagonal: 48.2°
• Horizontal: 40.8°
• Vertical: 27.8°

Included:

1x Meike 75mm T2.1 S35 Lens PL Mount
