SmallRig Cage for Panasonic DC-BGH1 3024

SmallRig Cage for Panasonic DC-BGH1 3024

SmallRig Cage for Panasonic DC-BGH1 3024 is designed to provide protection and a variety of accessory-mounting options for the Panasonic DC-BGH1 cinema camera. The cage secures to the camera via three 1/4”-20 screws, one on the top and two on the bottom to prevent twisting. The cage does not block buttons or interfaces and does not affect the use of XLR. Featuring multiple 1/4”-20, ARRI 3/8”-16 threads for accessory attachment such as Top Handle 2165, Monitor Holder 2903, and Magic Arm 2070. The left side integrates with a NATO rail for Side Handle 2187 to make your setup quick releasable. The right side comes with an ARRI rosette for Rosette Handle 1941 for handheld shooting. HDMI & USB-C Cable Clamp and lens adapter support are included in the package to protect the cable ports and lens ports. Besides, it comes with built-in flat head screwdriver stores on the bottom for quick installation.

Key Features:

1. Designed for Panasonic DC-BGH1 Cinema Camera.
2. Multiple 1/4”-20 & ARRI 3/8”-16 Accessory Mounts.
3. Integrated NATO Rail & ARRI Rosette.
4. Built-in Flat Head Screw Driver on the Bottom.
5. HDMI Cable Clamp & USB-C Cable Clamp & Lens Adapter Support Included.

Note: Please install the bottom 1/4”-20 screws first and then the top screw.

Compatibility:

Panasonic DC-BGH1

Compatibility of lens adapter:
Canon EF Lens to Micro Four Thirds T Smart Adapter (MB_EF-m43-BT2)
Canon EF Lens to Micro Four Thirds T Speed Booster XL 0.64x (MB_SPEF-M43-BT3)

Package Includes:

1 x Cage
4 x M4 screw
1 x HDMI & USB Cable Clamp
1 x Lens Adapter Support
2 x Allen wrench

Product Dimensions: 110.9 x 74.7 x 108.7mm
Package Dimensions: 165 x 155 x 85mm
Net Weight: 268g±5g
Package Weight: 395g±5g
Material(s): Aluminum Alloy
