Secced Reach Plus 3 Tripod Kit
Secced Reach Plus 3 Tripod Kit
Secced Reach Plus 3 Tripod Kit - 2
Secced Reach Plus 3 Tripod Kit - 3

Secced Reach Plus 3 Tripod Kit

€1 995
Add to list of favorites
Ler mais

Entrega: External warehouse. 5-12 Days Delivery

  • VAT free purchase available at checkout.

Descrição

Artigo n.: 1440

Secced Reach Plus 3 Tripod Kit

The fluid head of the Reach Plus 3 features a balance adjustment lever device designed to duplicate the available counterbalance steps. It is recommended for portable broadcast camcorders in ENG configuration, up to a load of 15.4 kg / 33.9 lb. The main components of the tripod kit are the fluid head with ø100 mm integrated ball, aluminum video tripod leg with floor-spreader and padded tripod bag.

Features Head: SC-V15/100RP

  • It has 0-20.8kg payload, it is a perfect gear to support most ENG configuration cameras.
  • Improved drag system enhances smoothness of head movement, matching the quality of most famous brand. In addition, graded drag adjustment ensure fast change of tilt and pan drag.
  • Step-type counterbalance system help operator to balance the camera in a minute without changing over and over to look for the right amount of counterbalance.
  • Quick release mechanism ensures operator to quickly mount or dismount the camera on the head.
  • All main parts are made with high quality CNC machine. It enhances parts machining precision, ensures high reliability and improves fluid head performance substantially.
  • In order to enhance rigidity of plastic parts, high quality hard plastic is adopted to manufacture all plastic parts of fluid heads, especially those control elements (brake level, clamp level etc.), which results in considerable high durability of SECCED fluid heads.
  • 100mm ball head, compatible with most 100mm tripod on the market.

Features  Tripod: SC-ENG/AL(CF)100D

  • Speed Locking system ensures quick setup of tripods and operators can get it ready for work within a minute.
  • Equipped with off ground and ground spreader.
  • All plastic parts adopt the imported material, enhance the quality of spare parts and ensure high rigidity of tripods.

Tehnical data

Reach Plus 3 Kit:

  • Weight: 8.96kg
  • Max Paylaod: 20.8kg
  • Height Range: 75-172mm
  • Bowl Diameter: 100mm
  • Transport Length: 90cm

Head:

  • Weight: 3.8 kg
  • Counterbalance: 0-15 steps
  • Sliding range-plate: 70mm
  • Grades of tilt drag: 0-7
  • Grades of pan drag: 0-7
  • Tilt range: -75°/+90°
  • Tripod fitting: 100mm

Payload:

C.O.G (mm) / Min Payload (kg) / Max Payload (kg)
75 / 0.00 / 20.87
100 / 0.00 / 17.22
125 / 0.00 / 15.40
150 / 0.00 / 13.62

Tripod:

  • Weight (With Ground Spreader): 5kg
  • Max. Payload: 35kg
  • Height Range (With Ground Spreader): 48-155cm
  • Height Range (With Off Ground Spreader): 55-151cm
  • Bowl Size: 100mm
  • Transport Length: 75cm
  • Extension: Double
  • Material: Aluminum

Included in the box

  • 1x Head SC-V15/100RP
  • 1x Tripod SC-ENG/AL(CF)100D
  • 1x Pan Bar SC-PB15
  • 1x Ground Spreader SC-FS100
  • 1x Padded Tripod Bag
