Smallhd 703 UltraBright On-Camera Monitor
£2,946.30
Smallhd 703 UltraBright On-Camera Monitor
- VAT free purchase available at checkout.
- BrandSmallhd
Description
Article no.: 4003
SmallHD 703 UltraBright
Bright monitor of 2200 nitsSmallHD 703 is a bright monitor made of aluminum, which means that it can withstand tough grips. The brightness is 2200 nits and the screen has a contrast of 1200: 1.
The front glass is optically joined to the screen panel, which provides a high viewing angle of 170 degrees. The front glass is of the Gorilla glass type, which makes it durable against, for example, scratches. There are three 1/4 inch threads, which means that the screen can be mounted in many different ways using an articulated arm or stand.
Software
Several functions are available for analysis of the image signal. Some of them are Anamorphic De-Squeeze, Image Rotate / flip, focus peaking, False Color, zebra, waveform, vectorscope, RGB parade, and histogram.
Cross conversion
The device can convert between HDMI and SDI or vice versa. Adds but on a LUT this can be applied to the converted output signal.
Power supply
The unit has a 2-pin LEMO connection and can be powered either by an AC adapter, D-tap cable or battery plate (purchased separately).
SD card slot
The SD card slot allows you to manage LUTs, saved images, update firmware and save profiles for settings
Format
SDI
YCC 4: 2: 2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i60, 1080i59.94, 1080i50
YCC 4: 2: 2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59 .94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
YCC 4: 2: 2 @ 10-bits: 480i29.97, 576i25
HDMI
YCC 4: 2: 2 @ 8 bits, 8/10/12 bit color in RGB & YCC 4: 4: 4: 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98,1080i60, 1080i59.94, 1080i50, 1080i30, 1080i29.97, 1080i25, 720p120, 720p119.88, 720p100, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p1.88, 480 480p60, 480p59.94, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 480i30, 480i29.97, 480i24, 480i23.98, 576i200, 576i100, 576i100, 576i100
Connections
SDI input
SDI combined input / output
HDMI input
HDMI output
Headphone connection 3.5 mm tele
Micro-USB
